June 26, 2013

How to Update Galaxy S3 (Canadian) SGH-I747M with Android 4.1.2 VLDMF1 Jelly Bean Official Firmware

Samsung has delivered a new software update based on Android 4.1.2 Jelly Bean with build number I747MVLDMF1 for the North American owners of Samsung Galaxy S3 bearing model number SGH-I747M - Rogers, Bell, Telus, and SaskTel.

Firmware details
PDA: I747MVLDMF1
CSC: I747MOYBDMF1
MODEM: I747MVLDMF1
Version: Android 4.1.2
Built date: Jun 3, 2013
Regions: Canada

The new official firmware is currently available as an Over-The-Air (OTA) update as well as through Samsung KIES. However, those who missed the OTA update notification or unable to access the update over Samsung KIES can download and install the same manually, using our step-by-step guide.

Pre-requisites
1. Install USB Driver for Samsung Galaxy S3 on the computer.
2. Enable USB Debugging Mode on the phone by navigating to Settings >> Developer Options.
3. Make a backup of all your important data before following the guide.
4. Ensure the battery of the phone is charged more than 80 per cent.
5. The Android 4.1.2 VLDMF1 Jelly Bean firmware is compatible only with Galaxy S3 (Canadian) SGH-I747M. Applying this to any incorrect variant might brick the device. Verify the model number of the Galaxy S3 by navigating to Settings >> About Phone.

Files Required
1. Android 4.1.2 VLDMF1 Jelly Bean Firmware for Galaxy S3 SGH-I747M
2. Odin 3.07

Steps to Update Galaxy S3 SGH-I747M with Android 4.1.2 VLDMF1 Jelly Bean Firmware
Step 1: Extract Firmware zip file that you downloaded already from above link using WinRAR/7-Zip/WinZip or any other extracting tool, you will get a .tar.md5 file and some other files.
Step 2: Extract Odin zip file and you will get Odin3 v3.07.exe along with few other files.
Step 3: Power off your phone. Wait 5-6 seconds for vibration to confirm complete switch off.
Step 4: Boot the device into Download Mode by pressing and holding Volume Down + Home buttons together and then press the Power button until the device turns on. Now press the Volume Up button to enter Download Mode.
Step 5: Run Odin on the computer as an Administrator.
Step 6: Connect the Galaxy S3 to the computer using USB cable while it is in the Download Mode. Wait until Odin detects the device. When the device is connected successfully, the ID: COM box will turn yellow with the COM port number. Additionally, the successful connected will be indicated by a message saying Added.
Step 7: Choose the following files in Odin from extracted I747MVLDMF1 firmware folder by using respective checkboxes:
  • Select the PDA checkbox, and choose the file named .tar or .md5.
  • Click the Phone checkbox, and choose the file with 'modem' in its name (ignore if there is no such file)
  • Click the CSC checkbox, and select the file with 'csc' in its name (ignore if such file is missing)
  • Choose the PIT checkbox, and choose the .pit file. Use only the file obtained during extracting in step 1 above, otherwise ignore it.
Step 8: In Odin, enable Auto Reboot and F. Reset Time checkboxes. Also, ensure the Re-Partition checkbox is chosen only if a .pit file was chosen in the previous step.
Step 9: Verify everything suggested in Step 7 and Step 8 is done correctly. Then hit the START button to begin the installation process.
Step 10: Once the installation process is completed, your phone will restart and soon you will see a PASS message with green background in the left-most box at the very top of the Odin. You can now unplug the USB cable to disconnect your device from computer.

Samsung Galaxy S3 SGH-I747M should be now updated with official Android 4.1.2 VLDMF1 Jelly Bean firmware. Head over to Settings >> About Phone to verify the software version running on the device.

Note: If Galaxy S3 SGH-I747M stuck at booting animation after Step 10 then go to recovery mode (press and hold the Volume Up, Home and Power buttons together) and perform Wipe data/Factory Reset and Wipe Cache Partition task before selecting reboot system now function. In recovery mode use Volume keys to navigate between options and Power key to select the option. Please note, performing wiping task will erase your device internal memory data and not external SD card data.

Click here to know How to Root Galaxy S3 (Canadian) SGH-I747M running on Android 4.1.2 VLDMF1 Jelly Bean firmware.

9 comments:

  1. Will this work on a rooted device?

    ReplyDelete
  2. i got stuck on nand write in the odin process i didn´t do anything after that i don´t know if you can help out with that

    ReplyDelete
  3. will it work for every carrier?

    ReplyDelete
  4. Thanks for the guide, 3 minutes and done :-)

    ReplyDelete
  5. Hi, thanks for the above. Can I use this method to downgrade from from 4.3 back to 4.1.2?
    I worry that 4.3 changed the partitioning by adding the multiple user feature.

    ReplyDelete
